Frank Dental

HP Carbide Cutter - Pear, Fine, Cross Cut - C.77KF

HP Carbide Cutter - Pear, Fine, Cross Cut - C.77KF

$12.95 USD
$12.95 USD
Sale Sold out
Diameter

HP carbide pear cutter C.77KF uses fine cross-cut geometry for controlled trimming, shaping and material reduction on CoCr, NiCr, base-metal casting alloys and non-precious RPD frameworks; gold casting alloys, noble palladium-based alloys and precious-metal PFM frameworks; PMMA denture-base resin, tray acrylic, CAD/CAM PMMA and bis-acryl provisional composite; and facing acrylics, composite veneering resins and layered veneering porcelain.

The pear form blends rounded access with controlled wall shaping in narrow areas and concave transitions. The tungsten carbide head and stable rotary design support efficient, controlled cutting performance in dental laboratory workflows.

  • Origin: Frank Dental, Germany
  • Shank: HP (2.35 mm)
  • Material: Tungsten Carbide
  • Shape: Pear
  • Grade: Fine
  • Blade pattern: Cross Cut
  • Color band: Red
  • Pack size: 1 piece


Available in the following configurations:

Order
code		 SKU Diameter Head
length		 Max.
RPM		 ISO
number
1721 C.77KF.104.014 1.4 mm 3.0 mm 40,000 500.104.237.140.014
1824 C.77KF.104.023 2.3 mm 4.0 mm 40,000 500.104.237.140.023
1703 C.77KF.104.029 2.9 mm 5.0 mm 40,000 500.104.237.140.029
1845 C.77KF.104.060 6.0 mm 11.0 mm 20,000 500.104.237.140.060
View full details
